Closed-cell polyisocyanurate (polyiso) foam core integrally bonded to inorganic coated glass facers. Tapered ACFoam-III is offered in a variety of slopes, to achieve positive drainage as well as long-term thermal resistance (LTTR). Available in 4ft x 4ft (1220mm x 1220mm) panels with 1/8” (3mm), 1/4” (6mm) and 1/2” (12mm) per foot slope. Manufactured in accordance with ASTM C1289, Type II, Class 2, Grade 2 (20 psi) or Grade 3 (25 psi) and CAN/ULC 704.1 Type 2, Class 2 or Type 3, Class 2.
Product Highlights
-
LTTR values up to 23.6
-
Available in 4'x4'
-
Available in 20 or 25 psi
-
Contains between 4.62% and 10.85% recycled materials by weight
-
Zero ozone depletion potential (ODP) and virtually no global warming potential (GWP)
-
Responsibly manufactured with zero CFCs, HCFCs, and HFCs
